Goodway Tube Scrubbers
Tube Scrubbers
€0,75

Cheaper somewhere else?

Let us know!

+31 183 216 170 [email protected]

Tube Scrubbers

Brand: Goodway
|
Article number: TS-560-S
Click to enlarge
€0,75 Excl. tax
€0,91 Incl. tax
In stock
You have got counting... hours

Tube Scrubbers are cheap and effective projectiles made to remove light and soft dirt from pipe bundles. Available for internal pipe diameters 12.6 to 31.75 millimetres. Use them in conjunction with the QS-300.

More info

Information

Introduction Tube Scrubbers

Tube Scrubbers are the cheapest and most used projectiles of Goodway Benelux. Perfect for removing light pollution in pipe bundles, heat exchangers and more. These Tube Scrubbers can be shot through the bundle quickly and easily by using a QS-300 or a BFP system.

These projectiles are made of Polyethylene material. This makes them strong enough to remove contamination, but not strong enough to damage the pipe material. This makes these projectiles an excellent replacement or even upgrade of the traditional high pressure cleaning. These projectiles are therefore also very interesting for cleaning titanium pipe bundles.

Deployment

Tube Scrubbers can be used almost everywhere where there is light soiling. The most common dirt that can be removed:

  • Algae
  • Mud
  • Sludge
  • Shells/Mossels (light)
  • Sand

This type(s) of pollution is often encountered at power plants and petrochemical plants. Especially in cooling systems thatuse river or sea water. For this the Tube Scrubbers are perfect.

Benefits Projectiles Cleaning

Cleaning with projectiles offers many advantages over traditional cleaning methods. Take a look at the biggest advantages below:

  • Speed. Time savings in projectile cleaning is enormous. You can shoot pipes of various lengths within seconds. With 2 persons you can clean about 1000 pipes per hour under the right conditions. That's faster than any method.
  • Cost reduction. Projectiles are relatively inexpensive and can be reused, so the cost per cleaning is much less than, for example, with high pressure. In addition, only one extra gun or system is needed to shoot through the projectiles. These are also for rent.
  • Safety. Projectiles are shot at low pressure. This is not only safer for the operators, but also for the installation itself. Pipes are not exposed to high pressures internally, such as high pressure cleaning of +500 bar or more.
  • Water consumption. Projectiles shoot through the pipe within seconds. So there is almost no water used to clean a pipe. Maybe a few liters per pipe, to rinse it clean.

Colour coding

ube Scrubbers are delivered color coded. This allows you to quickly distinguish which size of Tube Scrubber you are going to use. This is especially useful when the projectiles are dirty. From the color you can immediately see if it is the right size.

Working method Tube Scrubbers

Tube Scrubbers can be shot quickly and easily through the pipe bundle, you only need a system to physically push through the pipe. This is possible with both the QS-300 and the BFP system. Take a look at both systems to find out which one best suits your work. The working method is then very simple:

  1. Make sure you have enough scrubbers to clean the pipes. Tube Scrubbers can be reused about 2-4 times. So if you have 10,000 pipes, make sure you have at least 2500 projectiles.
  2. Provide an adequate launch system, such as the QS-300 or BFP.
  3. Pre-rinse the pipes with the launch system, to make sure the pipes are open and to soak the pollution.
  4. Put the projectiles in the pipes and shoot them with the system you are using.
  5. Hold the trigger for about 2 to 3 seconds. Hold for 1 or 2 seconds after the projectile has left the pipe. This ensures a better after rinsing.
  6. Catch the projectiles at the back, and then re-use them.

Check the table below to select the right Scrubber for your bundle:

Pipe Internal Diameter: Variant: Color: Product Code:
12.57 - 13.74 mm Soft Yellow TS-560-S
13.39 - 14.10 mm Hard Yellow TS-560
14.50 - 15.75 mm Soft Brown TS-630-S
15.00 - 16.00 mm Hard Brown TS-630
15.75 - 17.15 mm Soft Red TS-695-S
16.56 - 17.63 mm Hard Red TS-695
16.76 - 18.54 mm Soft Purple TS-750-S
18.03 - 19.05 mm Hard Purple TS-750
18.54 - 20.32 mm Soft White TS-825-S
19.74 - 20.80 mm Hard White TS-825
19.81 - 21.59 mm Soft Green TS-870-S
20.96 - 22.10 mm Hard Green TS-870
22.10 - 23.98 mm Soft Blue TS-960-S
22.50 - 24.13 mm Medium Blue TS-960-M
22.91 - 24.28 mm Hard Blue TS-960
25.40 - 27.56 mm Soft Black TS-1100-S
26.09 - 28.08 mm Hard Black TS-1100
27.94 - 30.23 mm Soft Grey TS-1250-S
30.23 - 31.75 mm Hard Grey TS-1250
Didn't find what you're looking for?
Let us help!
Specifications
Product
Article number:TS-560-S
